One hole Copper Cable Lugs 45 Degree(Australia)
PART NO Cable mm2 E (H.D.) A  (I.D.) C (O.D.) D B H G
CWAUS105H 10 5.2 4.7 7.1 12 10 6.4 6
CWAUS106H 10 6.5 4.7 7.1 12 10 6.4 6
CWAUS108H 10 8.4 4.7 7.1 14 10 7.5 7
CWAUS1010H 10 10.5 4.7 7.1 16 10 9.5 8
CWAUS1012H 10 13 4.7 7.1 18 11 12.5 10
CWAUS166H 16 6.5 5.5 7.9 11 19 8 7
CWAUS168H 16 8.4 5.5 7.9 14 19 8.4 7
CWAUS1610H 16 10.5 5.5 7.9 16 19 9.5 8
CWAUS1612H 16 13 5.5 7.9 18 19 12.5 10
CWAUS256H 25 6.5 7.1 9.5 14 21 8 7
CWAUS258H 25 8.4 7.1 9.5 14 21 8 7
CWAUS2510H 25 10.5 7.1 9.5 16 21 9 9
CWAUS2512H 25 13 7.1 9.5 18 21 12.5 10
CWAUS356H 35 6.5 8.2 11.2 16 21 9 9
CWAUS358H 35 8.4 8.2 11.2 16 21 9 9
CWAUS3510H 35 10.5 8.2 11.2 18 21 9 9
CWAUS3512H 35 13 8.2 11.2 20 22 12 11
CWAUS506H 50 6.5 9.5 12.8 18 22 9 8
CWAUS508H 50 8.4 9.5 12.8 18 22 9 8
CWAUS5010H 50 10.5 9.5 12.8 18 22 9 8
CWAUS5012H 50 13 9.5 12.8 21 22 12 11
CWAUS706H 70 6.5 11.2 14.3 21 24 12 11
CWAUS708H 70 8.4 11.2 14.3 21 24 12 11
CWAUS7010H 70 10.5 11.2 14.3 21 24 12 11
CWAUS7012H 70 13 11.2 14.3 21 24 12 11
CWAUS7016H 70 17 11.2 14.3 28 24 13 13
CWAUS958H 95 8.4 13.5 17.4 25 27 12.5 12
CWAUS9510H 95 10.5 13.5 17.4 25 27 12.5 12
CWAUS9512H 95 13 13.5 17.4 25 27 12.5 12
CWAUS9516H 95 17 13.5 17.4 28 27 14.5 14
CWAUS1208H 120 8.4 15.6 20.6 29 30 12.5 12
CWAUS12010H 120 10.5 15.6 20.6 29 30 12.5 12
CWAUS12012H 120 13 15.6 20.6 29 30 12.5 12
CWAUS12016H 120 17 15.6 20.6 29 30 14.5 16
CWAUS15010H 150 10.5 16.7 22.5 32 30 14.5 16
CWAUS15012H 150 13 16.7 22.5 32 30 16.5 18
CWAUS15016H 150 17 16.7 22.5 32 30 16.5 18
CWAUS18510H 185 10.5 18.4 24.2 35 32 14.5 16
CWAUS18512H 185 13 18.4 24.2 35 32 16.5 18
CWAUS18516H 185 17 18.4 24.2 35 32 16.5 18
CWAUS24010H 240 10.5 21.2 28.2 40 38 18.5 21
CWAUS24012H 240 13 21.2 28.2 40 38 18.5 21
CWAUS24016H 240 17 21.2 28.2 40 38 18.5 21
CWAUS30012H 300 13 23.5 31.3 45 42 20.5 23
CWAUS30016H 300 17 23.5 31.3 45 42 20.5 23
CWAUS400BLH 400 BL 26.8 34.8 50 44 25.5 24
CWAUS500BLH 500 BL 30.0 39.0 56 50 24.5 27
CWAUS630BLH 630 BL 34.0 45.0 65 58 28.5 32
